Product Pattern: YY1212P
Batteries materials：Lithium iron phosphate
Series parallel mode (S series, P parallel)：4S1P
Nominal voltage：12.8V
Nominal capacity:12Ah
Size（mm）：155*99*99
Weight：2.2kg
Color: Optional
Parallel support: Parallel terminals are supported
Output port mode：terminal
Charging way：CC/CP/VP
Charging current：0.2C(standard）
Maximum charging current：Max1.2C @25℃
Charge cut-off voltage：14.6V
Discharge way：CC/CP/VP
Discharge current：0.5C
Maximum discharge current：Max0.5C @25℃
Discharge cut-off voltage：11.2V
According to：LCD
Communication interface：RS485/RS232/CAN
Charging operating temperature：charging:0~+50℃
Discharge operating temperature：discharge:-20~+55℃
Warranty：5 years
Scope of application: hospital, bank data center, enterprise energy storage backup power supply, office, military, base station and other
