Model NO. | Product Parameters | |
YY48200LR | Batteries materials:Lithium iron phosphate Series parallel mode (S series, P parallel):15S1P Nominal voltage:48V Nominal capacity:200Ah Size(mm):490*484*250 Weight:79kg Color: Optional Parallel support: Parallel terminals are supported Output port mode:terminal Charging way:CC/CP/VP Charging current:0.2C(standard) Maximum charging current:Max1.2C @25℃ Charge cut-off voltage:58.4 Discharge way:CC/CP/VP Discharge current:0.5C Maximum discharge current:Max0.5C @25℃ Discharge cut-off voltage:44.8V According to:LCD Communication interface:RS485/RS232/CAN Charging operating temperature:charging:0~+50℃ Discharge operating temperature:discharge:-20~+55℃ Warranty:5 years Scope of application: hospital, bank data center, wall-mounted home, enterprise energy storage backup power supply, wind complementary system, office, military, base station and other uninterrupted energy storage power supply. |
|
Description
